Timing Chain Assemblies
A timing chain assembly is the complete set of chain, tensioner, guides and sprockets that keeps the crankshaft and camshafts synchronised.
What it does
The chain drives the camshafts from the crankshaft. The hydraulic tensioner maintains correct tension and the guides control the chain path so it does not slap or jump a tooth.
Signs a timing chain kit is failing
- A rattle from the timing cover on cold start
- Camshaft and crankshaft correlation fault codes
- Rough running, misfire or loss of power
- A rattle on sudden throttle changes
When to replace them
Not a fixed interval on most engines, but chain stretch and guide wear are common at higher mileage. Any cold-start rattle should be investigated immediately.
What to confirm before ordering
Have these ready and the counter can usually confirm the part in under a minute.
- Engine code from the block
- Whether the kit includes tensioner, guides and sprockets
- Whether the engine is an interference design
- Whether the timing cover gasket and front crankshaft seal are needed
Timing Chain Assemblies by vehicle
Pick your vehicle for the years and engines covered, and what is specific to that application.
Timing Chain Assemblies questions
Should the whole timing kit be replaced or just the chain?
Replace the assembly. Chain, guides and tensioner wear together, and the labour to reach them is identical, so fitting a new chain against worn guides simply brings the next failure forward.
What does a stretched timing chain sound like?
A rattle from the front of the engine on cold start, before oil pressure fills the tensioner. It typically quietens after a few seconds, which is exactly why it gets ignored.
